| Model | 3500W | 5500W |
| RATED POWER | 3500VA/3500W | 5500VA/5500W |
| Input | ||
| Voltage | 230VAC | |
| Selectable Voltage Range | 170~280VAC(For Personal Computers) | |
| 90~280VAC(For Home Appliances) | ||
| Frequency Range | 50 Hz/60Hz(Auto sensing) | |
| OUTPUT | ||
| AC Voltage Regulation(Batt.Mode) | 230VAC±5% | |
| Surge Power | 7000VA | 11000VA |
| Efficiency(Peak)PV to INV | 97% | |
| Efficiency(Peak)Battery to INV | 94% | |
| Transfer Time | 10 ms (For Personal Computers);20 ms (For Home Appliances) | |
| BATTERY & AC CHARGER | ||
| Battery Voltage | 24VDC | 48VDC |
| Floating Charge Voltage | 27VDC | 54VDC |
| Overcharge Protection | 33VDC | 63VDC |
| Maximum Charge Current | 80A | 80A |
| SOLAR CHARGER | ||
| Maximum PV Array Power | 5000W | 6000W |
| MPPT Range @ Operating Voltage | 120-450VDC | |
| Maximum PV Array Open Circuit Voltage | 500VDC | |
| Maximum Charging Current | 100A | 100A |
| Maximum Efficiency | 98% | |
| PHYSICAL | ||
| Dimension,D*W*H(mm) | 100*300*440 | |
| Net Weight(kgs) | 11 | 12 |
| Communication interface | RS232/GPRS/WIFI/Remove LCD | |
| OPERATING ENVIRONMENT | ||
| Humidity | 5% to 95% Relative Humidity(Non-condensing) | |
| Operating Temperature | 0°C-55°C | |
Integrated MPPT charge controller Equalization charging function Work with or without battery PV input voltage upto 450VDC Configurable grid or solar input priority Optional WIFI/GPRS remote monitoring
More
Integrated MPPT charge controller Configurable grid or solar input priority Optional WIFI/ GPRS remote monitoring Parallel for scalability
More
Pure sine wave solar inverter Output power factor 1.0 Wifi&GPRS available for IOS and android Inverter running without battery Built-in 100A MPPT solar charger High PV input voltage range(120~500VDC) Built-in anti-dusk kit for harsh environment Smart battery charge design to optimize battery life Built-in Remote LCD Display
More
